Type 98A Ke-Ni

Type 98A Ke-Ni 2022-11-08

The Type 98 light tank Ke-Ni or Type 98A Ke-Ni Ko (also known as Type 98 Chi-Ni light tank) was designed to replace the Imperial Japanese Army's Type 95 Ha-Go light tank, Japan's most numerous armored fighting vehicle during World War II. Although designed before World War II began, production did not start until 1942, with 104 being produced by the end of the war in the Pacific.

The design of the Type 98, in comparison to the Type 95, featured thicker, welded armor of improved shape, including the use of a Mitsubishi Type 100 6-Cylinder air-cooled diesel engine, rated at 130 horsepower, and located sideways to make maintenance easier. The height of the tank was 50 cm lower in profile, and slightly lighter and shorter in length than the original Type 95. It could travel at 50 km/h (31 mph) even with its thicker armor. Three pairs of bogies with six road-wheels connected to the chassis using bell cranks, which transferred any movement in the bogies into sideways motion that was absorbed by springs. This gave the tank better stability over its predecessor.

In contrast to the one-man turret of Type 95, the Type 98 had a two-man turret, which offered more room for the gunner/commander. In the turret was mounted a Type 100 37 mm tank gun with an angle of fire of -15 to +20 degrees, a muzzle velocity of 760 m/s, and also a coaxial 7.7 mm machine gun. The driver was located in a central position of the chassis. To maneuver the tank, he used a standard steering wheel.

The file contains the unit and pcx files. Model is not my own creation. Wyrmshadow helped with the animation files. I merely put the pieces together and cleaned up the model for CivIII and added some what if pieces. A big thanks to everyone that helped out!
  • Type98AKe-Ni.jpg
    677.5 KB · Views: 28
